Custom Forklift-Mounted Man Baskets Gallery

This forklift mounted man basket was designed and built for a waste water treatment facility maintenance division and will be applied on their heavy industrial and standard maintenance applications. This is equipped for a 3-person/1200 lb capacity and with casters for ease of maneuverability and storage when not mounted on a lift-truck.

Dimensions: 48″ X 60″ X 42″ High
Capacity: 1200 lbs
Model: EFL3-1200SO EF022505

This basket was built with dual-hinged mastguards, and two sets of fork tubes to allow OSHA-compliant lifting from two sides. The Quick Claw and pin system options allow for fast and secure attachment.

Dimensions: 48″ X 108″

Capacity: 1100 lbs

Model: EFL4-1600SO EF012504

Designed and built for specific underground mining electrical cable spooling operations with replaceable UHMW cable sheaves, this personnel platform has a height-adjustable spooling structure that adapts to either end of the man basket.

Dimensions: 72″ X 60″ X 42″
High Capacity: 3-Person, 1600 lbs
Model: EFL3-1600SO EF062494

Designed for a specialty alloy manufacturing plant, this forklift personnel platform is built to assist in lifting from any of the three sides. It features 3-way fork tubes, pin safety systems, and 3-way mast guards, allowing for the ultimate flexibility in accessing job site locations.

Dimensions: 48″ x X 62″ X 42″ High
Capacity: 3-Person, 1200 lbs
Model: EFL3-1200SO EF042488

Designed to be permanently attached to the customer’s fork truck, it
includes both ramp and gate access. An extra tool tray provides additional storage space, and the adjustable crash guard can be shifted left or right to protect personnel in varying conditions. The rubber bumpers on the front and side provide additional protection for the basket when positioned in close quarters.

Dimensions: 36″ X 37″ X 42″ High
Capacity: 2-Person, 700 lbs
Model: FL2-700SO F102383

Built for an underground mining company, this platform is designed to handle drilling and maintenance operations. It utilizes a modular removable overhead protection system built to accommodate multiple lifting platforms.

Dimensions: 48″ x 72”
Capacity: 5-Person, 1500 lbs
Model: EFL5-1500SO EF072370

With dual-use capability as a crane-suspended personnel platform and forklift hoisted personnel platform, these RECOFL2-600 baskets were purchased by a crane company for their new fleet of cranes supporting the wind energy sector. The RECOFL2-600 effectively doubles your equipment capacity with the dual-use capabilities. LT’s designs are the safest and most efficient available, providing quality and safety above all others.

Dimensions: 60″ X 36″ X 79″ High
Capacity: 2-Person, 600 lbs
Model: RECOFL2-600 EC062369

Designed for accessing an exceptionally narrow space in a manufacturing facility, this 26″ wide forklift personnel platform maximizes the available inside width with a modified placement of our inner grab rail, providing consistent fall protection anchorage and safe hand holds around the entire perimeter.

Dimensions: 96″ X 26″ X 42″ High
Capacity: 4-Person, 1600 lbs
Model: EFL4-1600SO EF022359

California compliant Forklift Work Platform with removable shelving system. This customer is using the platform to deliver and install large batteries. Each shelf has 300 lb. capacity

Dimensions: 57″ x X 60.5” X 84″ High
Capacity: 2-Person, 1800 lbs
Model: EFL2-1800SOCA EF042364

This stock picker platform is custom designed to handle loading and hoisting of products within the stock picker capacity but beyond the safe lifting weight of the operator, keeping the process ergonomically safe for the employee.

Dimensions: 44″ x  X 39” X 42″ High
Capacity: 2-Person, 800 lbs
Model: SP2-800  SP032345

Built for marina forklift hoisting of personnel to perform maintenance on upper levels of watercraft storage facilities, this custom forklift platform is equipped with custom fabricated fork tubes and custom safety chains to accommodate the marina forklift’s oversized forks.

Dimensions: 36″ x 84” X 42″ High
Capacity: 3-Person, 1200 lbs
Model: FL3-1200SO F022372

Designed for a railroad company. It has an open front with a removable bar at the top rail and safety chains across the front of the platform, which allows full access at the work destination. The bar stows conveniently on the back wall of the platform.

Dimensions: 48″ x 108″ X 42″ HIGH
Capacity: 4-Person, 1600 lbs
Model: EFL4-1600SO EF012355

This platform is designed for lifting personnel with either a crane or a forklift, eliminating the need for two separate platforms. In addition to the sling assembly, test weight system and security chains, it includes overhead protection to protect personnel from falling objects. One side is enclosed for protection from the forklift and has our pin system to secure it to the forklift to prevent shifting or sliding on the forks.

Dimensions: 60″ x 36″ x 79″ High
Capacity: 600 lbs
Model: RECOFL2-600 EC112237

This platform is designed to comply with California rules CAL OSHA 8CCR 3659 and 8CCR3657, which require a mast guard 84″ high and a solid floor in the platform. We satisfy that with a rubber mat. This platform is also custom-built to have no bar over the access opening to allow easier entry and exit of the platform.

Dimensions: 48″ x 48″ x 42″ High
Capacity: 800 lbs
Model: EFL2-800SOCA EF112252

This custom forklift man basket is designed for use as an integral safety system component of an OEM’s turnkey multi-level palletized goods storage system providing safe personnel access to upper levels for maintenance purposes.

Dimensions: 60″ L x 40″ W
Capacity: 700 lbs
Model: EFL2-700SO EF102249

This custom platform, SP2-800, is engineered with superior strength, and is designed to be used with a warehouse stock picker truck.

Dimensions: 48″ x 48″
Capacity: 2-person, 800lbs
Model: SP2-800 SP082243

This custom Professional Series Forklift with walk-through gate has bumpers on back side to prevent truck from hitting the backstop.

Dimensions: 42″ x 48″ X 42″ High
Capacity: 2-PERSON, 800 lbs
Model: EFL2-800SO EF0622442

This custom Professional Series EFL3-1000SO is a man basket designed with superior strength and frame support and engineered for working on pond liners.

Dimensions: 42” x 48”
Capacity: 1000 lbs
Model: EFL3-1000SO EF0622433

This custom Premier Series FL2-1000SO is designed with superior strength and frame support and engineered for underground mining construction. Heavy-duty bumpers strategically placed on all sides assist with the platform directly contacting mine shaft walls during use.

Dimensions: 72″ x 48″
Capacity: 2-person, 1000lbs
Model: FL2-1000SO F0322652

This professional forklift man basket has a gate and one tool tray. Instead of the QuickClaw system, it has a pin system to secure it to the forklift, making it much easier to disengage from the forklift on uneven surfaces.

Dimensions: 48″ x 48″ x 75″
Model: EFL2-800NQ EF0521152, EF0521162, EF0521172

This platform is built with a walk-through gate centered on the front, whereas our standard placement is on the side. The mast guard is collapsible, and the fork tubes utilize LT’s pin system to secure the forklift. The pin system is ideal when working in rough terrain, construction-type environments.

Dimensions: 48″x48″
Capacity: 2-man, 800lbs
Model: EFL2-800SO EF0421122

We showcase here a custom Professional Series forklift work platform designed specifically for siding contractors. It features a custom folding saw table with 30″ extensions, an adjustable height saw mounting plate, LT’s PIN system on 3 sides, an open front secured with safety chains, tool trays, and magnetic cup holders.This man basket is shipped to a construction company in New Hampshire.

Dimensions: 84″ X 48″
Capacity: 2-person, 1200lbs
Model: EFL3-1200SO EF0420843

This unique forklift platform is engineered with removable overhead protection, LT’s PIN system, and safety chains for an added safety connection to the forklift carriage. This was shipped to a quarry in Tennessee.

Dimensions: 48″L x 72″W x 75″H
Capacity: 3-person, 1200lbs
Model: EFL3-1200SOG EF0121063

EFL4-1600SO forklift personnel platform with tool tray and access bar opening on one end.

Dimensions: 48″ X 96″
Capacity: 4-person, 1600lbs
Model: EFL4-1600SO

This is a Professional Series forklift personnel platform with a walk-through gate, Lexan mast guard and tool tray.

Dimensions: 40″ x 36″
Capacity: 1-person, 400lbs
Model: EFL1-400SOG EF0518581

Removable sides and a fold down mast guard make this quite a unique forklift work platform. The inner grabrail is attached to the mast guard and provides fall protection anchorage while the fork tubes are equipped with LT’s pin system for an exceptional safe and secure attachment to the fork heels. Safety chains are provided on all our forklift personnel work platforms.

Dimensions: 48″ x 72″
Capacity: 2-person, 800lbs
Model: FL2-800SONQ F0919262

Custom built for Canadian mining company, this platform is engineered with an extra heavy-duty design and matte black powder coat finish with reflective striping.

Dimensions: 84″ x 36″
Capacity: 2-man, 500lbs
Model: FL3-1200SOG F0119173

This custom Premier Series FL5-1500SOG is designed with superior strength, frame support and engineered for underground mining construction. Heavy-duty bumpers strategically placed on all sides assist with the platform coming in direct contact with mine shaft walls during use.

Dimensions: 72″ x 48″.
Capacity: 5-person, 1500lbs
Model: FL5-1500SOG F0519215, F0519225

Custom SPQ2-700 stock picker platform with two access gates, adjustable to fit two stock picker models used at the customer’s facility

Dimensions: 48″ x 48″ x 48″ high.
Capacity: 2-person, 700lbs
Model: SPQ2-700 SP0820422

This platform is designed with LT’s Quick Claw Safety System and heavy-duty rubber bumpers on three sides. It has one tool tray and the mast guard ends at guardrail height making this optimal for use with telehandlers.

Dimensions: 72″ x 48″
Capacity: 5-person, 1500lbs
Model: FL5-1500SOG F0615485, F0615495

This dual-purpose personnel platform can be suspended with a forklift or crane. It is designed with fork tubes and our pin system for forklift and lifting eyes and our sling system for crane suspension. The collapsible mast guard folds down when rigged to a crane.

Dimensions: 48″ x 48″
Capacity: 2-man, 750lb
Model: SECFL2-750WA EC0820312
